K27 turbine metering fuel nozzle is
used to measure the volume flow rate of liquid passing through the pipe
and suitable for measuring gasoline and kerosend fuel, etc. The meter
has advantages as high accuracy and convenient carrying. As long as the
measured with drop height of 2-10 meters between the surface and the
instrument of medium, it can work normally without any additional power
source.
a. can be used for different media like gasoline, diesel, kerosene and other oil
b. high accuracy, light weight, compact volume makes it convenient for carrying
c. automatic shutoff function when oil transfer finish(oil reaching the nozzle spout hole)
d. precise and stable walking, simple operation
e. combine refueling with flowmeter
| Model Number |
CDI-N09 |
| Inlet&Outlet Size |
1' |
| Flowrate |
0-60 lpm |
| Accuracy | ±0.5% |
| Application Media |
gasoline, kerosene, diesel |
|
Material |
aluminum |
| Shutoff Sensitivity |
0.3 second |
| Working Pressure |
0.18Mpa |
| Package |
10 pcs/carton |
| N.W./ G.W. | 16.5kg/17.5kg |
| Dimension | 51x32x45 cm |
